Our company is one of the best professional suppliers for bellow equipment in China, providing many various pipeline fittings products,such as stainlesss steel flexible metal hose,metal/fabric bellows expansion joint, fire sprinkler flexible hose, PTFE bellows and others. Provides perfect after-sinales service and guidance ,please rest assured purchase.
Add: City East Development Zone,Jiangyan Area,Taizhou City, Jiangsu Province, China Mobile: 86-17321605009 Tel: 86-523-88588220 Fax: 86-523-88588220 Skype: luckylin5858 WhatsApp: 8617321605009 Wechat: 17321605009 Email: email@example.com
Thick-wall expansion joints are used primarily in heat exchangers and large diameter piping systems where thin-wall expansion joints would not be sufficient.The distribution of axial,angular,and lateral forces will be different when thick-wall pipe expansion joints are used.We can provide your design engineers with the potential forces and movements for proper design of the structural members supporting the system. Size: DN150~DN1000mm Bellow materials:SS304,SS316L,SS321 Standard:GB/T16749-1997
The expansion joint consists of one bellow and two flanges in two ends.It absorbs the axial displacement of the pipeline through the flexible deformation of the bellows.This kind of expansion joint is with simple structure and low price,so it should be given priority consideration wherever can used on pipeline. Flange standard:ANSI ,DIN,JIS,GB, BS Flange material: SS304,SS316L,SS321,carbon steel Bellow: SS304,SS316L,SS321 Inner sleeve: SS304,SS316L,SS321,carbon steel Ear plate/Tie rod/Nut: SS304,carbon steel
Our flanged flexible metal bellow hose is mainly used for pipe connection where there's high temperature and pressure in pipeline system. Flange standard can be ANSI,DIN,JIS,BS,GB etc; Flange materials can be stainless steel SS304,SS316L,SS321 or carbon steel according to different requirement; If non-standard flange required,we design and produce according to detail flange sizes. Operating temperature: -196~+600℃ Operating pressure: 15Mpa
Fustar rotary compensator is a new type of heat pipe heat expansion area of compensator,which installed on the heat pipe need to two or more group to group,form the relatively rotation absorption pipeline thermal displacement,so as to reduce the stress of pipeline.
