Availability: | |
---|---|
Quantity: | |
2 Inch(DN50)
Fustar
83071000
SS321 2 inch corrugated welding-neck flange flexible metal bellow hose
Size DN6(1/4”)- DN800(32”)
Fustar Bellows is a leading manufacture and supplier of flange flexible metal bellow hoses,also known as flexible metal hose assemblies. We offer a complete range of welding-neck flange flexible metal bellow hose from size DN6(1/4") ID to DN800(32")ID in SS321,SS3136L,SS304, manufactured in compliance with GB/T14525-2010.Our SS321 welding-neck metal bellow hose assemblies are available with a wide range of end connections bore sizes and lengths.We can supply corrugated metal bellow hose assemblies that meets your most demanding technical specifications.
SS321 flexible metal bellow hose can be supplied with or without stainless steel wire braiding.Wire braiding can be single or double.Generally,an external layer of SS wire braid is provided on corrugated flexible metal bellow hose,as an unbraided hose tends to elongate axially when pressure is applied.Some customers may even choose two or even three layers of braiding for high pressure applications. The braiding is highly flexible and follows the movement of the hose.
SS321 flexible metal bellow hoses offer very high-pressure resistance,vacuum tightness,thermal stability and corrosion resistance.
Construction and Specifications of Flange Flexible Metal Bellow Hose
Fixed&Loosen flanges ends drawing | |||
NO.S | ITEMS | MATERIALS (Stainless steel) | REMARK |
1 | Floating & smaller flange | SS304/SS316L/SS321/carbon steel | ANSI,DIN,JS,GB,BS etc |
2 | Inner Bellow | SS304/SS316L/SS321 | Annular/Helical corrugation |
3 | Outer Braids | SS304/SS316 | no/1/2/3 layer |
4 | Fixed flange | SS304/SS316L/SS321/SS201 | ANSI,DIN,JIS,GB,BS etc |
Fixed flanges in both ends drawing | |||
NO.S | ITEMS | MATERIALS (Stainless steel) | REMARK |
1 | Fixed flange both ends | SS304/SS316L/SS321/carbon steel | ANSI,DIN,JIS,GB,BS etc |
2 | Inner Bellow | SS304/SS316L/SS321 | Annular/Helical corrugation |
3 | Outer Braids | SS304/SS316 | no/1/2/3 layer |
Tube/Hose Material: 321 stainless steel,316L stainless steel,316 stainless steel
External Braiding Material:321 stainless steel,304 stainless steel
Quality Assurance-SS321 Corrugated Welding-neck Flanged Flexible Metal Bellow Hose
In Fustar Bellows,all welding-neck flange flexible metal bellow hoses are leak tested and are subject to strict inspection at each stage of the production process from raw material purchasing to product dispatch.All raw material used in the manufacture of hoses,braiding and end connections are tested to ensure complicance with international standards and customer requirements.
We supply inspection report after testing finished flange flexible metal bellow hoses from our inspection department,the reports are put into package together with finished goods for deliverying, or we send customer by courier company as required.
SS321 2 inch corrugated welding-neck flange flexible metal bellow hose
Size DN6(1/4”)- DN800(32”)
Fustar Bellows is a leading manufacture and supplier of flange flexible metal bellow hoses,also known as flexible metal hose assemblies. We offer a complete range of welding-neck flange flexible metal bellow hose from size DN6(1/4") ID to DN800(32")ID in SS321,SS3136L,SS304, manufactured in compliance with GB/T14525-2010.Our SS321 welding-neck metal bellow hose assemblies are available with a wide range of end connections bore sizes and lengths.We can supply corrugated metal bellow hose assemblies that meets your most demanding technical specifications.
SS321 flexible metal bellow hose can be supplied with or without stainless steel wire braiding.Wire braiding can be single or double.Generally,an external layer of SS wire braid is provided on corrugated flexible metal bellow hose,as an unbraided hose tends to elongate axially when pressure is applied.Some customers may even choose two or even three layers of braiding for high pressure applications. The braiding is highly flexible and follows the movement of the hose.
SS321 flexible metal bellow hoses offer very high-pressure resistance,vacuum tightness,thermal stability and corrosion resistance.
Construction and Specifications of Flange Flexible Metal Bellow Hose
Fixed&Loosen flanges ends drawing | |||
NO.S | ITEMS | MATERIALS (Stainless steel) | REMARK |
1 | Floating & smaller flange | SS304/SS316L/SS321/carbon steel | ANSI,DIN,JS,GB,BS etc |
2 | Inner Bellow | SS304/SS316L/SS321 | Annular/Helical corrugation |
3 | Outer Braids | SS304/SS316 | no/1/2/3 layer |
4 | Fixed flange | SS304/SS316L/SS321/SS201 | ANSI,DIN,JIS,GB,BS etc |
Fixed flanges in both ends drawing | |||
NO.S | ITEMS | MATERIALS (Stainless steel) | REMARK |
1 | Fixed flange both ends | SS304/SS316L/SS321/carbon steel | ANSI,DIN,JIS,GB,BS etc |
2 | Inner Bellow | SS304/SS316L/SS321 | Annular/Helical corrugation |
3 | Outer Braids | SS304/SS316 | no/1/2/3 layer |
Tube/Hose Material: 321 stainless steel,316L stainless steel,316 stainless steel
External Braiding Material:321 stainless steel,304 stainless steel
Quality Assurance-SS321 Corrugated Welding-neck Flanged Flexible Metal Bellow Hose
In Fustar Bellows,all welding-neck flange flexible metal bellow hoses are leak tested and are subject to strict inspection at each stage of the production process from raw material purchasing to product dispatch.All raw material used in the manufacture of hoses,braiding and end connections are tested to ensure complicance with international standards and customer requirements.
We supply inspection report after testing finished flange flexible metal bellow hoses from our inspection department,the reports are put into package together with finished goods for deliverying, or we send customer by courier company as required.
