Availability: | |
---|---|
Quantity: | |
DN25
Fustar
83071000
Specifications
Material Features | |
Bellow Hose | AISI 316 Stainless Steel |
Sprinkler Connection | AISI304/AISI316 |
Extension Pipe | AISI304/AISI316 |
Braiding wire | AISI 304 Stainless Steel |
Fire Line Connections | AISI304/AISI316/Carbon Steel |
Connection Adapter | Carbon Steel |
Dimensions | |
Nominal Diameter | DN20(3/4”) ,DN25(1”) |
Connection | 1” nipple x 1/2” Special sprinkler head connection 1” nipple x 3/4” (Optional) |
Standard Length | 500mm-700mm-1000mm-1500mm-2000mm |
Friction Losses and Specifications | ||||
Hose Length | Input End | Output End | Max.No of 90℃ Bends | Max. Pressure |
0.5M | 1 inch | 1/2 inch | 3 | 20 bar |
0.7M | 1 inch | 1/2 inch | 4 | 20 bar |
1.0M | 1 inch | 1/2 inch | 4 | 20 bar |
1.5M | 1 inch | 1/2 inch | 4 | 20 bar |
2.0M | 1 inch | 1/2 inch | 4 | 20 bar |
Features
· Fully assembled for ease of installation.
· One-piece brackets available in 24″ and 48″ width.
· No tools required for bracket installation.
· Compatible with pendant, semi-recessed and concealed sprinkler heads.
· Hose lengths from 28″ to 71″ long.
· Outlet sizes available in 1/2″ and 3/4″.
· Unbraided and braided hose assemblies.
Application
Hotel, theatre, cinema, library Hospital, school, residential building Sport Centres, Business Buildings Government Buildings All high buildings Shopping Malls
Specifications
Material Features | |
Bellow Hose | AISI 316 Stainless Steel |
Sprinkler Connection | AISI304/AISI316 |
Extension Pipe | AISI304/AISI316 |
Braiding wire | AISI 304 Stainless Steel |
Fire Line Connections | AISI304/AISI316/Carbon Steel |
Connection Adapter | Carbon Steel |
Dimensions | |
Nominal Diameter | DN20(3/4”) ,DN25(1”) |
Connection | 1” nipple x 1/2” Special sprinkler head connection 1” nipple x 3/4” (Optional) |
Standard Length | 500mm-700mm-1000mm-1500mm-2000mm |
Friction Losses and Specifications | ||||
Hose Length | Input End | Output End | Max.No of 90℃ Bends | Max. Pressure |
0.5M | 1 inch | 1/2 inch | 3 | 20 bar |
0.7M | 1 inch | 1/2 inch | 4 | 20 bar |
1.0M | 1 inch | 1/2 inch | 4 | 20 bar |
1.5M | 1 inch | 1/2 inch | 4 | 20 bar |
2.0M | 1 inch | 1/2 inch | 4 | 20 bar |
Features
· Fully assembled for ease of installation.
· One-piece brackets available in 24″ and 48″ width.
· No tools required for bracket installation.
· Compatible with pendant, semi-recessed and concealed sprinkler heads.
· Hose lengths from 28″ to 71″ long.
· Outlet sizes available in 1/2″ and 3/4″.
· Unbraided and braided hose assemblies.
Application
Hotel, theatre, cinema, library Hospital, school, residential building Sport Centres, Business Buildings Government Buildings All high buildings Shopping Malls
