Size dn 3/8" to 6" Bronze fitting wire braided vibration absorbers

3/8" to 6" Bronze fitting wire braided vibration absorber is made of deep pitch corrugated tubing for increasing tube flexibility and vibration absorption,covered by high tensile stainless steel mesh for superior strength,and the copper tube tube connected to internal thread is welded by high temperature brazed alloys.
Copper Joint: Copper
Corrugated bellow: SS304,SS316L,SS321
Braids: SS304
Welding tube : SS304
Availability:
Quantity:
  • 3/8" to 6"

  • Fustar

  • 83071000

Size dn 3/8" to 6" Bronze fitting wire braided vibration absorbers

Fustar vibration absorbers are ideal for installations especially in refrigerating systems.Wire braided vibration absorbers are used for absorbing vibrations caused by compressors,pumps and motors.


The main function of a vibration absorber(vibration eliminator) is to absorb compressor vibration. By installing a vibration eliminator,the risk of damage to system equipment and pipework is reduced.


Bronze vibration absorbers made of stainless steel are attached to copper pipes using silver welding.Indicated braided vibration absorber lengths are to meet vibration conditions (frequency and amplitude) related to regular compressor production standards.


Construction and Specifications

Vibration absorber drawing
                   vibration absorber_副本

NO.S ITEMS MATERIALS (Stainless steel) REMARK
1 Copper Joint Copper/SS304 /carbon steel -------------
2 Welding Fitting SS304 -------------
3 Corrugated Pipe SS304/SS316/SS321 Annular/Helical corrugation
4 Outer Braids SS304/SS316L no/1/2/3 layer
5 Jacket SS304 --------------

Main Features
Proven design

Large hose ID

Stainless steel hose and braid

Stainless steel ferrules for superior strength

Helium leak tested


Applications
3/8" to 6" vibration absorber can be installed in both the suction and discharge lines of air-conditioning and refrigeration systems.

Vibration absorbers are suitable for HCFC,HFC AND CO₂ refrigerants, along with their associated oils.
